DIN 472 Specifications

Fasteners, Best Quality Fasteners

All measurements in millimeters (mm)

d1	s	d3
M3	0.4	2.7
M4	0.4	3.7
M5	0.6	4.7
M6	0.7	5.6
M7	0.8	6.5
M8	0.8	7.4
M9	1	8.4
M10	1	9.3
M11	1	10.2
M12	1	11
M13	1	11.9
M14	1	12.9
M15	1	13.8
M16	1	14.7
M17	1	15.7
M18	1.2	16.5
M19	1.2	17.5
M20	1.2	18.5
M21	1.2	19.5
M22	1.2	20.5
M23	1.2	21.4
M24	1.2	22.2
M25	1.2	23.2
M26	1.2	24.2
M27	1.2	25.1
M28	1.5	25.9
M29	1.5	26.9
M30	1.5	27.9
M31	1.5	28.7
M32	1.5	29.6
M33	1.5	30.5
M34	1.5	31.5
M35	1.5	32.2
M36	1.75	33.2
M37	1.75	34.2
M38	1.75	35.2
M39	1.75	35.8
M40	1.75	36.5
M41	1.75	37.5
M42	1.75	38.5
M44	1.75	40.5
M45	1.75	41.5
M46	1.75	42.5
M47	1.75	43.5
M48	1.75	44.5
M50	2	45.8
M52	2	47.8
M54	2	49.8
M55	2	50.8
M56	2	51.8
M57	2	52.8
M58	2	53.8
M60	2	55.8
M62	2	57.8
M63	2	58.8
M65	2.5	60.8
M67	2.5	62.6
M68	2.5	63.5
M70	2.5	65.5
M72	2.5	67.5
M75	2.5	70.5
M77	2.5	72.5
M78	2.5	73.5
M80	2.5	74.5
M82	2.5	76.5
M85	3	79.5
M87	3	81.5
M88	3	82.5
M90	3	84.5
M92	3	84.5
M95	3	89.5
M97	3	89.5
M98	3	89.5
M100	3	94.5
M102	3	94.5
M105	4	98
M107	4	98
M108	4	98
M11
